UPVC Tee
Three-Way Branch Connection Fitting
This is a fitting for three-pipe junctions or branches. The T-shaped design has one inlet and two outlets, or vice versa. It can diversion media from the main pipe to two branches. Or it can merge media from two branches into the main pipe. The socket-type connections make installation simple and reliable. You can use it in industrial piping branch lines, water supply riser and branch connections, chemical multi-point supply systems, and sprinkler system branch lines. We manufacture all our tees on 10 injection molding machines. Our molds are precise. Wall thickness is uniform. Socket dimensions are accurate.

Industrial plastic pipe series products

CPVC Electricity

CPVC

PE

PPH

PVDF

UPVC
Our products match our pipes perfectly. The socket and spigot fit tightly. This ensures no leakage after solvent cement bonding. Our tees have been widely used in clean room piping systems for China Electronics System Engineering No.2 and No.3 Construction. Our R&D team of 4 people can develop non-standard sizes or special angle tees. All our fittings come with factory inspection reports and certificates. Standard products ship in 3-5 working days.
Quality and After-Sales Support

We accept third-party inspections. We perform 100% inspection and regular sampling before shipment. A 12-month warranty covers every piece. If goods are damaged due to packaging or quality issues, we replace them free. We provide free samples (shipping costs are negotiable). Custom sample development takes 45 days. Our team responds within 4 hours by phone and arrives on site within 24 hours. We conduct quarterly phone follow-ups and semi-annual on-site inspections during the warranty. Contact us at 400-881-6180 or reach our account manager at 18056040225.

One-stop Tube Factory in China
You can call us at 400-881-6180.
Our account manager is also available at 17315849196.
Dimensional Specifications
|
Size (DN) |
Socket OD D1 (mm) |
End OD D2 (mm) |
Socket Depth L1 (mm) |
Center Distance L2 (mm) |
Overall Height L3 (mm) |
|
DN20 |
25.3 |
31.9 |
19.0 |
48.93 |
66.0 |
|
DN40 |
50.45 |
60.25 |
31.5 |
88.75 |
116.0 |
|
DN65 |
75.5 |
88.91 |
44.0 |
127.47 |
166.0 |
|
DN125 |
140.6 |
161.47 |
76.0 |
227.5 |
295.5 |
|
DN250 |
281.5 |
314.8 |
147.0 |
448.0 |
552.0 |
All three ports have the same size. This is a straight tee.
