CPVC Flange
Detachable Connection for Hot Media Equipment
This fitting provides detachable connections between CPVC pipes and equipment or valves handling hot media. Flange connections allow easy installation, inspection, and replacement of piping. You do not need solvent cement for this connection. Bolts provide the sealing force. This makes maintenance much simpler. You can disconnect and reconnect without damaging the pipe ends. The fitting inherits CPVC's heat resistance up to 93°C. You will use these at chemical plant equipment interfaces with hot media, pump inlet and outlet connections, and filter connections. Any location needing frequent disassembly benefits from this fitting.
Industrial plastic pipe series products
CPVC Electricity
CPVC
PE
PPH
PVDF
UPVC
Our CPVC flanges use imported CPVC material. The flange face is flat and smooth. Bolt hole positions are accurate. Our flanges work with Chinese, American, and Japanese standard metal backing rings. We hold ISO9001, ISO14001, and ISO45001 certifications. Products come with complete material certificates and test reports. We have built relationships with China Wuye Group and China Railway Construction Corporation. Monthly capacity is 3,000 tons. We can handle large flange orders without delay.
Quality and After-Sales
We accept third-party inspections. We do 100% checks before packing. A 12-month warranty covers every piece. For non-human damage, we replace free of charge. We support EXW, FOB, and DDP trade terms. Export packaging uses wooden pallets for safety. Our team responds within 4 hours by phone. We arrive on site within 24 hours. Contact us at 400-881-6180.
One-stop Tube Factory in China
You can call us at 400-881-6180.
Our account manager is also available at 17315849196.
Flange Dimension Table
|
Size (DN) |
Inner Diameter D0 (mm) |
Flange OD D1 (mm) |
Bolt Circle (mm) |
Bolt Holes |
Pressure Rating |
|
DN25 |
45.7 |
115 |
85 |
4-φ14 |
PN16 |
|
DN50 |
78.4 |
165 |
125 |
4-φ18 |
PN16 |
|
DN100 |
127.9 |
220 |
180 |
8-φ18 |
PN16 |
|
DN150 |
186.3 |
285 |
240 |
8-φ22 |
PN16 |
|
DN250 |
283.3 |
395 |
350 |
12-φ22 |
PN10 |
These dimensions follow standard flange specifications.
