CPVC Cap
End Closure Fitting for Hot Media Pipelines
This fitting closes the end of a CPVC pipe in hot media systems. It is also called a CPVC plug or CPVC end cover. You install it at the end of a pipeline or at reserved connection points. It prevents media leakage and keeps foreign materials out of the pipe. The socket-type design uses solvent cement bonding for a permanent seal. The fitting inherits CPVC's heat resistance up to 93°C. You will use it for end closures in hot water piping systems. It also works for temporarily closing ports during pressure testing. And it serves as protection for reserved connections that are not yet in use.
Industrial plastic pipe series products
CPVC Electricity
CPVC
PE
PPH
PVDF
UPVC
We manufacture all our CPVC caps using imported CPVC material on our own injection molding machines. Our molds are precise. Dimensions match our CPVC pipes accurately. Wall thickness is uniform. We hold ISO9001, ISO14001, and ISO45001 certifications. Anhui Province recognizes us as a High-Tech Enterprise. Our caps have been used in projects for China Nuclear Huatai Construction and China Construction Eighth Engineering Division. Each batch comes with a factory inspection report. Standard products ship in 3-5 working days.
Quality and Service
We accept third-party inspections. We check every cap before packing. A 12-month warranty covers every piece. If goods are damaged due to packaging or quality issues, we replace them free. Our team responds within 4 hours by phone. We arrive on site within 24 hours. Contact us at 400-881-6180.
One-stop Tube Factory in China
You can call us at 400-881-6180.
Our account manager is also available at 17315849196.
Cap Dimension Table
|
Size (DN) |
End OD D0 (mm) |
Socket OD d1 (mm) |
Socket Depth T (mm) |
Total Height L (mm) |
Pressure Rating |
|
DN20 |
31.8 |
25.3 |
18.7 |
25.7 |
S5(PN20) |
|
DN40 |
61.9 |
50.4 |
31.2 |
44.7 |
S5(PN20) |
|
DN65 |
91.2 |
75.4 |
43.7 |
62.6 |
S6.3(PN16) |
|
DN125 |
161.6 |
140.8 |
76.2 |
109.7 |
S6.3(PN16) |
|
DN200 |
259.4 |
226.2 |
119.1 |
170.4 |
S6.3(PN16) |
Each cap has accurate dimensions for proper fitting.
