PVDF Plastic Pipe

PVDF Plastic Pipe

This product is made from polyvinylidene fluoride, a high-performance fluoroplastic. It offers exceptional chemical resistance. The pipe withstands strong acids, strong bases, organic solvents, and oxidizing agents. It also provides excellent temperature resistance up to 150°C continuously.
Send Inquiry
Description
Technical Parameters

Pvdf Plastic Pipe

High-Performance Pipe for Extreme Conditions

This product is made from polyvinylidene fluoride, a high-performance fluoroplastic. It offers exceptional chemical resistance. The pipe withstands strong acids, strong bases, organic solvents, and oxidizing agents. It also provides excellent temperature resistance up to 150°C continuously. The pipe has good mechanical strength and wear resistance. The inner surface is extremely smooth and resists scaling. You can use it for semiconductor high-purity chemical transport, photovoltaic corrosive chemical lines, pharmaceutical sterile media transfer, and high-temperature aggressive chemical systems. We are recognized as a High-Tech Enterprise in Anhui Province. This certification proves our technical capability in high-performance material R&D and production.

product-1200-800

Industrial plastic pipe series products



product-800-800

CPVC Electricity

CPVC

CPVC

PE

PE

PPH

PPH

PVDF

PVDF

UPVC1

UPVC

Our R&D team of 4 people focuses on processing technology for specialty engineering plastics. We operate 7 extrusion lines and 10 injection molding machines. We can produce high-quality pipes and fittings. We hold multiple utility model patents related to piping. We work with major domestic state-owned enterprises. Our product quality is rigorously verified. We can manufacture based on your technical drawings. Custom sample development takes 45 days.



Quality and After-Sales Support

product-1200-800

We support OEM and ODM services. We can manufacture based on your technical drawings or prototypes. There is no minimum order quantity. Custom sample development takes 45 days. We can provide samples before mass production. Standard products ship in 3-5 working days. Custom products take 45 working days. A 12-month warranty covers every piece. If goods arrive damaged due to packaging or quality issues, we replace them free. Our team responds within 4 hours by phone. For urgent cases, we complete repairs within 24 hours. Contact us at 400-881-6180.

modular-1
One-stop  Tube Factory in China

You can call us at 400-881-6180.

Our account manager is also available at 17315849196.



Pressure Ratings and Wall Sizes



Nominal Diameter (DN)

Outer Diameter (Φmm)

PN1.0 Wall (mm)

PN1.6 Wall (mm)

DN25

32

2.4

2.9

DN50

63

3.0

4.7

DN80

90

4.3

6.7

DN125

140

6.7

10.3

DN200

225

10.8

16.9

The long-term operating temperature range is -40°C to 150°C.
